| Type | Loa Passive 1 Bass 30cm + 1 Treble |
| Frequency Response(-6dB anechoic chamber) | 45Hz-20KHz |
| Rated power(AES) | 500W |
| Maximum Calculated SPL/1M | 133dB |
| Horizontal Coverage Angle (Symmetrical) | 60° |
| Vertical Coverage Angle (Symmetrical) | 40° |
| LF Driver | Customized Audiocenter ferrite driver, 3” voice coil, 500W(AES) |
| HF Driver | Customized Beyma ferrite driver, 1.0” exit, 1.75” voice coil, 70W(AES) |
| Crossover Point | 1500Hz |
| Impedance | 8Ω(+1, -1) |
| 1 Way Amplifier | 2pcs maximum, 4Ω |
| Hanging Points | M8 screw |
| Pole Mount | Base hole Φ35mm |
| Input Connectors | 2×NEUTRIK® NL4MP |
| Cabinet Material | CNC made of excellent wood |
| Cabinet Color | Black is standard and default color.Consult with sales team for the other customized colors. |
| Dimension(W×H×D) | 374×608×378mm |
| Net Weight | 23.5Kg |
