ype |
Active DSP-controlled Compact Subwoofer |
Frequency Response(-6dB anechoic chamber) |
35Hz-150Hz |
Maximum Calculated SPL/1M |
137dB |
LF Driver |
Customized Audiocenter ferrite driver, 4” voice coil |
AMPLIFIER |
|
Amplifier Circuitry |
Class D |
Power(Peak) |
2000W |
Frequency Response(1W 8Ω 2ch) |
20Hz-6KHz(±0.5dB) |
Intermodulation Distortion |
<0.05% |
Total Harmonic Distortion |
<0.05% |
Protection |
DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
Cooling System |
Cooling with fans, air convection |
DSP |
|
Processor |
96KHz signal sampling frequency, 24bit precision |
Presets |
80Hz,100Hz, 120Hz |
Crossover |
Controlled by DSP |
Output / Input |
|
Signal Input |
1×NEUTRIK® female XLR |
Signal Output |
1×NEUTRIK® male XLR |
Power Input |
3 pin plug |
Working Voltage |
100V-130V/60Hz or 220V-240V/50Hz |
Cabinet |
|
Cabinet Material |
CNC made of excellent wood |
Cabinet Color |
Black is standard and default color. Consult with Audiocenter sales team for other customized colors |
Dimension(W×H×D) |
510×625×712mm |
Net Weight |
42.5Kg |
